Mechanical Concrete Crusher
Features :
- Mechanical Structure, Low vibration, Low noise and easy to maintenance.
- Easy to install by using U-bend, Good visibility from the carrier machine
- Concrete strength should be lower than 50N/mm2
- Magnet is optional.
Specifications
| Model | NGC-70 | NGC-120 | NGC-200 | NGC-300 |
|---|---|---|---|---|
| Excavator Weight (t) | 6~7 | 10~15 | 20~25 | 30~35 |
| Max. Opening Size (mm) | 520 | 900 | 1200 | 1500 |
| Front Crushing Power (N/mm²) | 140 | 210 | 300 | 500 |
| Center Crushing Power (N/mm²) | 160 | 330 | 520 | 700 |
| Overall Weight (kg) | 280 | 800 | 1200 | 2100 |
| Crushed Size (mm) | 100~200 | 100~200 | 100~200 | 100~200 |
| 24V Magnet (Option) | Φ350 | 400x300 | 500x400 | 600x500 |
