Hydraulic Pulverizer
Features :
- Equipped with a speed valve that helps to speed up the crushing process.
- 24/220 V Magnet is choseable.
- More durable body by using Hardox steel.
- Hydaulic generator can be combined in the body.
Specifications
| Model | MGC-70 | MGC-120 | MGC-200 | MGC-300 |
|---|---|---|---|---|
| Excavator Weight (t) | 6 ~ 7 | 10 ~ 15 | 20 ~ 25 | 30 ~ 35 |
| Front Crushing Power (ton) | 45 | 69 | 82 | 120 |
| Opening Size (mm) | 520 | 770 | 810 | 950 |
| Oil Pressure (Mpa) | 27.5 | 34.3 | 34.3 | 34.3 |
| Oil Flow (l/min) | 80 | 150 | 200 | 300 |
| Overall Weight (kg) | 780 | 1240 | 2050 | 3100 |
| Magnet Diameter (mm) | 300 | 600 | 750 | 900 |
